Nordfab Quick-Fit Ducting

nordfab-quick-fit


With this versatile and easy to use clamp together duct you can say goodbye to complicated cutting, riveting and brazing. Installing Quick-Fit ducting is so easy it can be done in HALF the time it would take to put in traditional ductwork. This saves you big money with less downtime, and less time spent on labor and special tools.

No complicated cutting, no riveting, no brazing or welding required. One Q-F clamp connects sections together in seconds. Branches, diverters, elbows - all adapt easily to your existing duct and may be taken apart and re-used or cleaned without special tools. Simply place the clamp over the rolled lip ends and snap! The extraordinary strength of Q-F's specially machined doubled rolled lips provides a solid, straight run. The patented Q-F clamp connects the rolled ends. Snap the Q-F clamp and you have the strongest, safest, most re-usable dust extraction piping available. No special instructions or skills are need to assemble a Quick-Fit system. Install new lines, clean out lines or make changes to existing duct runs anytime you need to with Q-F.

Quick-Fit adapts to your every need

Connect to the old or bring in the new Q-F has everything you need in galvanized and stainless steel parts:

  • Laser Welded pipe in diameters from 3" to 24"
  • Branch fittings in all sizes and shapes
  • Elbows in 30°, 45°, 60°, 90°
  • Larger custom sizes and special adapters
  • Square to Round duct adapters
  • Spark Traps and Explosion Isolation
  • Blast Gates, Diverter Valves, Hoods, Manifolds
boatbuiling-dust-extraction

5 Reasons Nordfab Quick-Fit Ducting is Perfect for Your Business

  1. Less downtime
    Q-F goes up in half the time of conventional duct.

  2. No special tools
    Your order comes with everything you need.

  3. Easy to install
    No need to hire special labor, anyone can snap a clamp together.

  4. Easy to clean
    Just unhook a section of duct, or use a special cleaning window for easy access anywhere in your run.

  5. Made in the USA
    Rest easy knowing you've got high quality, laser welded duct, made by American hands.

Call (248) 496-7375
to talk with a ducting expert.
or email us at ctassociates@msn.com

What industries use Nordfab ducting?


You can find Nordfab's Quick-Fit ducting in a wide variety of industries and businesses including:

Lime processing, weld fume extraction, oil mist collection, paper processing, coffee roasting, wood dust collection, chemical dust collection, pharmaceutical labs, condensation control, textile production, and many more.

Nordfab Quick-Fit Pipe

The main component of the Nordfab ducting system, these pipes come in 5ft sections and can be ordered in a variety of diameters and guages, in both galvanized and stainless steel. Each section comes with the clamps needed to connect it to the rest of the system, elminating the need for special tools and labor.

Nordfab quick-fit ducting is available in diameters from 3" to 24". For the toughest applications QF ducting can be ordered in 14, 16, or 18 guage steel.

nordfab-qf-pipe

Quick-Fit Ball Joint

When your dust collection system requires flexibility the QF ball joint provides up to 22° of movment.

While elbows are set at a fixed angle and direction the ball joint provides you with 360° directional capability and an angle from 0-22°, depending on your application.

nordfab-qf-ball-joint

Blast Gates

Available in automatic and manual, QF blast gates add an extra level of control in your dust extraction process. Single cylinder gates are available in 3" to 8", and two cylinder models from 9" to 22". Available in galvanized or stainless steel.

nordfab-qf-blast-gate

Viewing Spool

Sometimes seeing material move through your system is extremely important. For those processes we provide a clear viewing window made of acrylic in diameters from 3" to 18". This simple addition to your run can help prevent costly downtown and keep your operation running efficiently.

Please note, due to the acrylic material the max temperature for the viewing port is 225°F. The standard QF rolled edge can be changed to a raw ID, raw OD, no fitting, hose adapter, flat flange, angle flange, or vanstone.

nordfab-viewing-spool

Oil Mist Recycler

This item minimizes the amount of oil flowing through your ductwork by capturing it early on and feeding it back to machinery. It can be installed vertically or horizontally. Consists of recycler unit, molded gasket, clamp and end cap.

nordfab-oil-mist-recycler

In-Line Spark Trap

The chances of a fire in your cyclone or collector can be greatly reduced with the Nordfab In-line Spark Trap. With minimal pressure loss, and no moving parts, this spark trap operates on the principle of disrupting the laminar airflow causing sparks to cool and extinguish before they can enter the cyclone or collector.

The In-line Spark Trap fits easily into existing Quick-Fit ducting systems, and can be added to other systems with a simple adapter. It can be removed for easy cleaning and requires no calibration. The Nordfab In-line Spark Trap is a simple, inexpensive way to reduce the incidence of fires.

nordfab-inline-spark-trap
